INA GE45-AW-A

Price: 271.31 $

Specifications

Brand	INA
Item Number	GE45-AW-A INA
Manufacturer Part Number	0066517120000
Also known as	GX45F
EAN	4012802532647
Category	Spherical Plain Bearing

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	120
Width (B) MM	36,5
Inner (d) Inch	1.7717
Outer (D) Inch	4.7244
Width (B) Inch	1.437
Weight (kg)	2.265 kg

Product Properties

Seal	No Seal
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	120
Height (T) mm	36,5
Width inner ring (B) mm	31
Axial Static Load Rating C0a (N)	2430000
Axial Dynamic Load Rating Ca (N)	1460000
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design

Suffix description

Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
