INA GE100-AW-A

Price: 1,222.35 $

Specifications

Brand	INA
Item Number	GE100-AW-A INA
Manufacturer Part Number	0066520340000
Also known as	GX100F
EAN	4012802532838
Category	Spherical Plain Bearing

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	210
Width (B) MM	59
Inner (d) Inch	3.937
Outer (D) Inch	8.2677
Width (B) Inch	2.3228
Weight (kg)	11 kg

Product Properties

Seal	No Seal
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	210
Height (T) mm	59
Width inner ring (B) mm	50
Axial Static Load Rating C0a (N)	6020000
Axial Dynamic Load Rating Ca (N)	3610000
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design

Suffix description

Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
