INA GAR45-UK-2RS-A

Specifications

Brand	INA
Item Number	GAR45-UK-2RS-A INA
Manufacturer Part Number	0066466620000
Also known as	SAA45TXE-2RS
EAN	4012802529197
Category	Rod End

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	102
Width (B) MM	35
Inner (d) Inch	1.7717
Outer (D) Inch	4.0157
Width (B) Inch	1.378
Weight (kg)	2.55 kg

Product Properties

Seal	2RS - Rubber Seal on Two Sides
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	68
Outer eye diameter (d 2) mm	102
Radial Static Load Rating C0r (N)	259000
Width inner ring (B) mm	32
Radial Dynamic Load Rating Cr (N)	360000
Basic static load rating, radial (C 0r)	"259000.0000"
Total length external thread rod (l 2) mm	214
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with external thread, right hand thread, maintenance-free, sliding layer: ELGOGLIDE DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, sealed

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
2RS	Lip Seals On Both Sides
A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
