INA GAL6-UK

INA GAL6-UK
INA GAL6-UK rulman resim 1
INA GAL6-UK rulman resim 2
INA GAL6-UK rulman resim 3
Price: 22.93 $
Specifications
Brand INA
Item Number GAL6-UK INA
Manufacturer Part Number 0066339190000
Also known as SAL6C
EAN 4012802524840
Category Rod End
Weight and Dimensions
Inner (d) MM 6
Outer (D) MM 21
Width (B) MM 6
Inner (d) Inch 0.2362
Outer (D) Inch 0.8268
Width (B) Inch 0.2362
Weight (kg) 0.013 kg
Product Properties
Seal No Seal
Contact Material Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 14
Outer eye diameter (d 2) mm 21
Radial Static Load Rating C0r (N) 6930
Width inner ring (B) mm 6
Radial Dynamic Load Rating Cr (N) 3600
Basic static load rating, radial (C 0r) "6930.0000"
Total length external thread rod (l 2) mm 46,5
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design
Suffix description
UK Sliding Contact Surface Hard Chromium/PTFE Composite
