INA GAL25-UK

INA GAL25-UK
INA GAL25-UK rulman resim 1
INA GAL25-UK rulman resim 2
INA GAL25-UK rulman resim 3
INA GAL25-UK rulman resim 4
Price: 69.76 $
Specifications
Brand INA
Item Number GAL25-UK INA
Manufacturer Part Number 0066337810000
Also known as SAL25C
EAN 4012802547504
Category Rod End
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 65
Width (B) MM 20
Inner (d) Inch 0.9843
Outer (D) Inch 2.5591
Width (B) Inch 0.7874
Weight (kg) 0.5 kg
Product Properties
Seal No Seal
Contact Material Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 42
Outer eye diameter (d 2) mm 64
Radial Static Load Rating C0r (N) 105000
Width inner ring (B) mm 20
Radial Dynamic Load Rating Cr (N) 51100
Basic static load rating, radial (C 0r) "105000.0000"
Total length external thread rod (l 2) mm 126
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design
Suffix description
UK Sliding Contact Surface Hard Chromium/PTFE Composite
