INA GAL20-UK

INA GAL20-UK
INA GAL20-UK rulman resim 1
INA GAL20-UK rulman resim 2
INA GAL20-UK rulman resim 3
INA GAL20-UK rulman resim 4
Price: 46.43 $
Specifications
Brand INA
Item Number GAL20-UK INA
Manufacturer Part Number 0066307310000
Also known as SAL20C
EAN 4012802523072
Category Rod End
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 54
Width (B) MM 16
Inner (d) Inch 0.7874
Outer (D) Inch 2.126
Width (B) Inch 0.6299
Weight (kg) 0.28 kg
Product Properties
Seal No Seal
Contact Material Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 35
Outer eye diameter (d 2) mm 53
Radial Static Load Rating C0r (N) 75600
Width inner ring (B) mm 16
Radial Dynamic Load Rating Cr (N) 31300
Basic static load rating, radial (C 0r) "75600.0000"
Total length external thread rod (l 2) mm 104,5
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design
Suffix description
UK Sliding Contact Surface Hard Chromium/PTFE Composite
