INA GAL10-UK
Price: 24.77 $
Specifications
| Brand | INA |
| Item Number | GAL10-UK INA |
| Manufacturer Part Number | 0066336840000 |
| Also known as |
SAL10C |
| EAN | 4012802524604 |
| Category | Rod End |
| Inner (d) MM | 10 |
| Outer (D) MM | 29 |
| Width (B) MM | 9 |
| Inner (d) Inch | 0.3937 |
| Outer (D) Inch | 1.1417 |
| Width (B) Inch | 0.3543 |
| Weight (kg) | 0.051 kg |
| Seal | No Seal |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 19 |
| Outer eye diameter (d 2) mm | 29 |
| Radial Static Load Rating C0r (N) | 20600 |
| Width inner ring (B) mm | 9 |
| Radial Dynamic Load Rating Cr (N) | 8640 |
| Basic static load rating, radial (C 0r) | "20600.0000" |
| Total length external thread rod (l 2) mm | 62,5 |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
| UK | Sliding Contact Surface Hard Chromium/PTFE Composite |
