INA GAKR12-PW-A

Price: 25.17 $

Specifications

Brand	INA
Item Number	GAKR12-PW-A INA
Manufacturer Part Number	0066334980000
Also known as	SAKB12F
EAN	4012802524239
Category	Rod End

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	34
Width (B) MM	16
Inner (d) Inch	0.4724
Outer (D) Inch	1.3386
Width (B) Inch	0.6299
Weight (kg)	0.1 kg

Product Properties

Seal	No Seal
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	26
Outer eye diameter (d 2) mm	32
Radial Static Load Rating C0r (N)	20800
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	24000
Basic static load rating, radial (C 0r)	"20800.0000"
Total length external thread rod (l 2) mm	70
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end GAKR..-PW, external threads, maintenance-free

Suffix description

Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
