INA BK2016-A

Price: 6.27 $

Specifications

Brand	INA
Item Number	BK2016-A INA
Manufacturer Part Number	0001770590000
EAN	4012802432503
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	20
Outer (D) MM	26
Width (B) MM	16
Inner (d) Inch	0.7874
Outer (D) Inch	1.0236
Width (B) Inch	0.6299
Weight (kg)	0.024 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	20
Radial Static Load Rating C0r (N)	20100
Radial Dynamic Load Rating Cr (N)	12700
Basic static load rating, radial (C 0r)	"20100.0000"
Limiting speed (n G)	12700
Limiting speed for grease lubrication (n G Grease)	7600
Reference speed (n u03d1r)	9300
ECLASS number	23-05-09-06
ECLASS2 number	23-05-09-06
Medias description	Drawn cup needle roller bearings with closed end BK, to DIN 618/ISO 3245

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
