INA AXK90120-A/0-10

Price: 21.06 $

Specifications

Brand	INA
Item Number	AXK90120-A/0-10 INA
Manufacturer Part Number	0000357699065
EAN	4012802369892
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	90
Outer (D) MM	120
Width (B) MM	4
Inner (d) Inch	3.5433
Outer (D) Inch	4.7244
Width (B) Inch	0.1575
Weight (kg)	0.077 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	120
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	405000
Axial Dynamic Load Rating Ca (N)	73000
Limiting speed (n G)	2750
Raceway dimension (E a) mm	118
Raceway dimension (E b) mm	94
Reference speed (n u03d1r)	1120
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
