INA AXK85110-A/0-10

Price: 19.65 $

Specifications

Brand	INA
Item Number	AXK85110-A/0-10 INA
Manufacturer Part Number	0000357429065
EAN	4047643173216
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	85
Outer (D) MM	110
Width (B) MM	4
Inner (d) Inch	3.3465
Outer (D) Inch	4.3307
Width (B) Inch	0.1575
Weight (kg)	0.053 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	110
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	290000
Axial Dynamic Load Rating Ca (N)	58000
Limiting speed (n G)	2950
Raceway dimension (E a) mm	108
Raceway dimension (E b) mm	89
Reference speed (n u03d1r)	1220
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
