INA AXK75100-A/0-10

Price: 12.80 $

Specifications

Brand	INA
Item Number	AXK75100-A/0-10 INA
Manufacturer Part Number	0000357009065
EAN	4012802371116
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	75
Outer (D) MM	100
Width (B) MM	4
Inner (d) Inch	2.9528
Outer (D) Inch	3.937
Width (B) Inch	0.1575
Weight (kg)	0.0512 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	100
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	265000
Axial Dynamic Load Rating Ca (N)	55000
Limiting speed (n G)	3300
Raceway dimension (E a) mm	98
Raceway dimension (E b) mm	79
Reference speed (n u03d1r)	1350
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
