INA AXK7095-A/0-10

Specifications

Brand	INA
Item Number	AXK7095-A/0-10 INA
Manufacturer Part Number	0000356889065
EAN	4012802369007
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	95
Width (B) MM	4
Inner (d) Inch	2.7559
Outer (D) Inch	3.7402
Width (B) Inch	0.1575
Weight (kg)	0.049 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	95
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	255000
Axial Dynamic Load Rating Ca (N)	54000
Limiting speed (n G)	3500
Raceway dimension (E a) mm	93
Raceway dimension (E b) mm	74
Reference speed (n u03d1r)	1430
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
