INA AXK5070-A/0-10

Price: 4.94 $

Specifications

Brand	INA
Item Number	AXK5070-A/0-10 INA
Manufacturer Part Number	0000355809065
EAN	4012802606096
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	50
Outer (D) MM	70
Width (B) MM	3
Inner (d) Inch	1.9685
Outer (D) Inch	2.7559
Width (B) Inch	0.1181
Weight (kg)	0.02 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	70
Rolling element diameter (D W) mm	3
Axial Static Load Rating C0a (N)	143000
Axial Dynamic Load Rating Ca (N)	32000
Limiting speed (n G)	4800
Raceway dimension (E a) mm	68
Raceway dimension (E b) mm	55
Reference speed (n u03d1r)	1950
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
