INA AXK150190-A/0-10

Specifications

Brand	INA
Item Number	AXK150190-A/0-10 INA
Manufacturer Part Number	0000359559065
EAN	4047643173292
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	150
Outer (D) MM	190
Width (B) MM	5
Inner (d) Inch	5.9055
Outer (D) Inch	7.4803
Width (B) Inch	0.1969
Weight (kg)	0.232 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	190
Rolling element diameter (D W) mm	5
Axial Static Load Rating C0a (N)	960000
Axial Dynamic Load Rating Ca (N)	143000
Limiting speed (n G)	1690
Raceway dimension (E a) mm	187
Raceway dimension (E b) mm	156
Reference speed (n u03d1r)	660
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
