INA AXK1226-A/0-10

Price: 2.09 $

Specifications

Brand	INA
Item Number	AXK1226-A/0-10 INA
Manufacturer Part Number	0000351739065
EAN	4012802399301
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	26
Width (B) MM	2
Inner (d) Inch	0.4724
Outer (D) Inch	1.0236
Width (B) Inch	0.0787
Weight (kg)	0.003 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	26
Rolling element diameter (D W) mm	2
Axial Static Load Rating C0a (N)	29000
Axial Dynamic Load Rating Ca (N)	9900
Limiting speed (n G)	15200
Raceway dimension (E a) mm	25
Raceway dimension (E b) mm	14
Reference speed (n u03d1r)	6500
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
