INA AXK120155-A/0-10

Price: 45.64 $

Specifications

Brand	INA
Item Number	AXK120155-A/0-10 INA
Manufacturer Part Number	0000358239065
EAN	4012802369021
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	120
Outer (D) MM	155
Width (B) MM	4
Inner (d) Inch	4.7244
Outer (D) Inch	6.1024
Width (B) Inch	0.1575
Weight (kg)	0.13 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	155
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	680000
Axial Dynamic Load Rating Ca (N)	102000
Limiting speed (n G)	2090
Raceway dimension (E a) mm	153
Raceway dimension (E b) mm	125
Reference speed (n u03d1r)	810
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
