INA AXK110145-A/0-10

Price: 35.21 $

Specifications

Brand	INA
Item Number	AXK110145-A/0-10 INA
Manufacturer Part Number	0000358079065
EAN	4012802369045
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	110
Outer (D) MM	145
Width (B) MM	4
Inner (d) Inch	4.3307
Outer (D) Inch	5.7087
Width (B) Inch	0.1575
Weight (kg)	0.122 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	145
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	620000
Axial Dynamic Load Rating Ca (N)	97000
Limiting speed (n G)	2260
Raceway dimension (E a) mm	143
Raceway dimension (E b) mm	115
Reference speed (n u03d1r)	890
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
