INA AXK100135-A/0-10

Price: 25.94 $

Specifications

Brand	INA
Item Number	AXK100135-A/0-10 INA
Manufacturer Part Number	0000357859065
EAN	4054364468392
Category	Needle Roller Thrust Bearing

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	135
Width (B) MM	4
Inner (d) Inch	3.937
Outer (D) Inch	5.315
Width (B) Inch	0.1575
Weight (kg)	0.104 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	135
Rolling element diameter (D W) mm	4
Axial Static Load Rating C0a (N)	560000
Axial Dynamic Load Rating Ca (N)	91000
Limiting speed (n G)	2420
Raceway dimension (E a) mm	133
Raceway dimension (E b) mm	105
Reference speed (n u03d1r)	970
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
