INA 71816-TN

INA 71816-TN
INA 71816-TN rulman resim 1
INA 71816-TN rulman resim 2
INA 71816-TN rulman resim 3
INA 71816-TN rulman resim 4
Price: 219.17 $
Specifications
Brand INA
Item Number 71816-TN INA
Manufacturer Part Number 0096211480000
EAN 4047643189293
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 80
Outer (D) MM 100
Width (B) MM 10
Inner (d) Inch 3.1496
Outer (D) Inch 3.937
Width (B) Inch 0.3937
Weight (kg) 0.101 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 10
Radial Static Load Rating C0r (N) 19100
Radial Dynamic Load Rating Cr (N) 16500
Basic static load rating, radial (C 0r) "19100.0000"
Limiting speed (n G) 8000
Reference speed (n u03d1r) 3900
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 718..-TVH, single row
Suffix description
TN Polyamide Cage
