INA 3810-2Z
Price: 69.77 $
Specifications
| Brand | INA |
| Item Number | 3810-2Z INA |
| Manufacturer Part Number | 0009721340000 |
| EAN | 4012802029215 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 50 |
| Outer (D) MM | 65 |
| Width (B) MM | 12 |
| Inner (d) Inch | 1.9685 |
| Outer (D) Inch | 2.5591 |
| Width (B) Inch | 0.4724 |
| Weight (kg) | 0.07 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 12 |
| Radial Static Load Rating C0r (N) | 10200 |
| Radial Dynamic Load Rating Cr (N) | 8500 |
| Basic static load rating, radial (C 0r) | "10200.0000" |
| Limiting speed (n G) | 8100 |
| Reference speed (n u03d1r) | 5400 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring |
| 2Z | Gap Seals At Both Sides Of The Bearing |
