INA 210-KRR-B-AH02

Specifications

Brand	INA
Item Number	210-KRR-B-AH02 INA
Manufacturer Part Number	0008984490000
EAN	4012802807622
Category	Deep Groove Ball Bearings Single Row

Weight and Dimensions

Inner (d) MM	38,1
Outer (D) MM	90
Width (B) MM	30
Inner (d) Inch	1.5
Outer (D) Inch	3.5433
Width (B) Inch	1.1811
Weight (kg)	0.733 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

ECLASS number	23-05-08-01
ECLASS2 number	23-05-08-01

Suffix description

K	Conrad (Non-Filling Slot) Type
RR	Two Land Riding Rubber Seals
B	Bearing With Spherical Outer Ring
AH02	Different Inner Diameter From Basic Part Number
