INA 208-XL-KRR-AH04

Specifications

Brand	INA
Item Number	208-XL-KRR-AH04 INA
Manufacturer Part Number	0009132430000
Also known as	208-KRR-AH04
EAN	4012802806557
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	38,892
Outer (D) MM	80
Width (B) MM	27,5
Inner (d) Inch	1.5312
Outer (D) Inch	3.1496
Width (B) Inch	1.0827
Weight (kg)	0.44 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Width (b) mm	27,5
Radial Static Load Rating C0r (N)	19800
Radial Dynamic Load Rating Cr (N)	34500
Basic static load rating, radial (C 0r)	"19800.0000"
ECLASS number	23-05-08-01
ECLASS2 number	23-05-08-01
Medias description	Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
AH04	Differing From Standard Design
