INA 203-XL-KRR-AH05
Price: 14.83 $
Specifications
| Brand | INA |
| Item Number | 203-XL-KRR-AH05 INA |
| Manufacturer Part Number | 0008083930000 |
| Also known as |
203-KRR-AH05 |
| EAN | 4012802783445 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 13 |
| Outer (D) MM | 40 |
| Width (B) MM | 18,3 |
| Inner (d) Inch | 0.5118 |
| Outer (D) Inch | 1.5748 |
| Width (B) Inch | 0.7205 |
| Weight (kg) | 0.06 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RS - Rubber Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 18,3 |
| Radial Static Load Rating C0r (N) | 4750 |
| Radial Dynamic Load Rating Cr (N) | 10100 |
| Basic static load rating, radial (C 0r) | "4750.0000" |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides |
| XL | X-Life |
| K | Conrad (Non-Filling Slot) Type |
| RR | Two Land Riding Rubber Seals |
| AH05 | Bore Size Different Than Standard |
INA 203KRR AH05
0.06 kg
13x40x18,3 mm
INA 203-KRR-AH05
0.06 kg
13x40x18,3 mm
IBU Fiedler 203KRR AH05
0.06 kg
13x40x18,3 mm
China 203KRR AH05
0.06 kg
13x40x18,3 mm
Neutral 319 8702
0.06 kg
13x40x18,3 mm
Neutral 203KRR
0.09 kg
13x40x18,3 mm
Neutral 203KRR AH05
0.06 kg
13x40x18,3 mm
INA 203-XL-KRR-AH05-C3
0.06 kg
13x40x18,3 mm
NBS 203KRR
0.09 kg
13x40x18,3 mm
INA Q203-KRR-CC-AH02
0.098 kg
13x40x18,3 mm
SWH Q203KRR-CC-AH02
0.098 kg
13x40x18,3 mm
INA 203KRR AH01
0.08 kg
13x40x18,3 mm
INA 203KRR AH13
0.08 kg
13x40x18,3 mm
INA 203KRR AH14
0.08 kg
13x40x18,3 mm
China 203KRR AH01
0.08 kg
13x40x18,3 mm
