INA 203-XL-KRR-AH02-C5

Specifications

Brand	INA
Item Number	203-XL-KRR-AH02-C5 INA
Manufacturer Part Number	0008083180050
Also known as	203-KRR-AH02-C5
EAN	4012802783476
Category	Deep Groove Ball Bearings Single Row

Weight and Dimensions

Inner (d) MM	16,2
Outer (D) MM	40
Width (B) MM	18,3
Inner (d) Inch	0.6378
Outer (D) Inch	1.5748
Width (B) Inch	0.7205
Weight (kg)	0.06 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	C5 Internal Play (Higher than C4)
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Width (b) mm	18,3
Radial Static Load Rating C0r (N)	4750
Radial Dynamic Load Rating Cr (N)	10100
Basic static load rating, radial (C 0r)	"4750.0000"
ECLASS number	23-05-08-01
ECLASS2 number	23-05-08-01
Medias description	Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides

Suffix description

XL	X-Life
K	Conrad (Non-Filling Slot) Type
RR	Two Land Riding Rubber Seals
AH02	Different Inner Diameter From Basic Part Number
C5	Bearing Internal Clearance Greater Than C4
