GMN Paul Müller Industrie S61804C TA HG RI DUL GMN Paul Müller Industrie

Name: GMN Paul Müller Industrie S61804C TA HG RI DUL GMN Paul Müller Industrie
Brand: GMN Paul Müller Industrie
SKU: EM-I-112855
Rating: 4.1 (2 reviews)

Price: 384.05 $

Specifications

Brand	GMN Paul Müller Industrie
Item Number	S61804C TA HG RI DUL GMN Paul Müller Industrie
Also known as	71804P4
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	20
Outer (D) MM	32
Width (B) MM	14
Inner (d) Inch	0.7874
Outer (D) Inch	1.2598
Width (B) Inch	0.5512
Weight (kg)	0.036 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	HG - GMN High Precision
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	DL - 2 Univ Bearings Light Preload
Lubrication	Standard Lubrication

Suffix description

C	15° Contact Angle
TA	Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring
HG	Gmn High Precision According To Gmn Specification
RI	Indication Of The Point Of Radial Runout (Maximum Wall Thickness On Inner Ring
DUL	2 Bearings, Universal Matching - Light Preload
