FAG XCS71914-E-T-P4S-DUL

Specifications

Brand	FAG
Item Number	XCS71914-E-T-P4S-DUL FAG
Manufacturer Part Number	0387414400000
EAN	4026677601537
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	110
Width (B) MM	32
Weight (kg)	1.12 kg

Product Properties

Seal	2RU - Two Seals / Non Contact Type
Cage Type	TB - Hard Fiber Cage
Precision	P4S Precision (Higher than P4)
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	DL - 2 Univ Bearings Light Preload
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Width (b) mm	16
Basic static load rating, radial (C 0r)	11700
Limiting speed for grease lubrication (n G Grease)	24000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL	Set Of 2 Universal Bearings, Light Preload
