FAG XCS71914-C-T-P4S-UL

Specifications

Brand	FAG
Item Number	XCS71914-C-T-P4S-UL FAG
Manufacturer Part Number	0387297920000
EAN	4026677584298
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	110
Width (B) MM	16
Inner (d) Inch	2.7559
Outer (D) Inch	4.3307
Width (B) Inch	0.6299
Weight (kg)	0.56 kg

Product Properties

Seal	2RU - Two Seals / Non Contact Type
Cage Type	TB - Hard Fiber Cage
Precision	P4S Precision (Higher than P4)
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Width (b) mm	16
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL	Single Bearing, Universal, Light Preload
