FAG XCS7005-E-T-P4S-DTL
Price: 1,104.14 $
Specifications
| Brand | FAG |
| Item Number | XCS7005-E-T-P4S-DTL FAG |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 25 |
| Outer (D) MM | 47 |
| Width (B) MM | 24 |
| Weight (kg) | 0.18 kg |
| Seal | 2RU - Two Seals / Non Contact Type |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | DT - Tandem Arrangement, 2 |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 12 |
| Basic static load rating, radial (C 0r) | 2650 |
| Limiting speed for grease lubrication (n G Grease) | 56000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DT | Set Of 2 Bearings Tandem Arrangement |
| L | Light Preload |
Barden C105FFT5 GJ-308
0.13 kg
25x47x24 mm
FAG B7005-E-T-P4S-DUL
0.1532 kg
25x47x24 mm
FAG HCS7005-C-T-P4S-DUL
0.184 kg
25x47x24 mm
FAG HCB7005-C-T-P4S-DUL
0.13 kg
25x47x24 mm
FAG HC7005-C-T-P4S-DUL
0.18 kg
25x47x24 mm
FAG HS7005-C-T-P4S-DUL
0.16 kg
25x47x24 mm
FAG B7005-C-2RSD-T-P4S-DUL
0.16 kg
25x47x24 mm
FAG B7005-C-T-P4S-DUL
0.16 kg
25x47x24 mm
FAG B7005-E-2RSD-T-P4S-DUL
0.146 kg
25x47x24 mm
FAG HSS7005-E-T-P4S-DUL
0.16 kg
25x47x24 mm
FAG HSS7005-C-T-P4S-DUL
0.16 kg
25x47x24 mm
SNFA EX25/NS 7CE3 TL
0.15 kg
25x47x24 mm
SKF 7005CE/P4ADGA
0.148 kg
25x47x24 mm
SNFA VEX25/NS SQ CE3 T
0.15 kg
25x47x24 mm
RHP 7005ETDUMP4
0.15 kg
25x47x24 mm
SKF 7005CE/PA9ADT
0.128 kg
25x47x24 mm
RHP 7005CSN24TRDULP3
0.15 kg
25x47x24 mm
RHP T7005CTDULP3
0.15 kg
25x47x24 mm
SKF S7005CE/P4ADBA
0.15 kg
25x47x24 mm
SKF 7005CE/PA9ADGA
0.128 kg
25x47x24 mm
SKF 7005ACD/P4ADGA
0.15 kg
25x47x24 mm
RHP 7005CTDULP4
0.15 kg
25x47x24 mm
SKF 7005CX/P4ADBB
0.15 kg
25x47x24 mm
SKF 7005CE/HCPA9ADGA
0.128 kg
25x47x24 mm
RHP 7005A5TRDULP3
0.15 kg
25x47x24 mm
RHP 7005A5TRDUMP3
0.15 kg
25x47x24 mm
SKF 7005CE/HCP4ADGA
0.13 kg
25x47x24 mm
SKF 7005 CE/PA9ADT
0.15 kg
25x47x24 mm
SKF 7005CD/P4ADBG20
0.15 kg
25x47x24 mm
NSK 7005CTYDBC8P5
0.16 kg
25x47x24 mm
NSK 7005A5TRDULP3
0.15 kg
25x47x24 mm
Fafnir 3MMV9105WI CR DUL
0.15 kg
25x47x24 mm
NSK 7005CTYDUM
0.172 kg
25x47x24 mm
NSK 7005CTRDUMP3
0.15 kg
25x47x24 mm
GMN Paul Müller Industrie BHT6005C TAM UP GUL 50N GMN Paul Müller Industrie
0.16 kg
25x47x24 mm
NSK 7005CTYNDULP4
0.15 kg
25x47x24 mm
