FAG WS22308-E1-XL-2RSR

Specifications

Brand	FAG
Item Number	WS22308-E1-XL-2RSR FAG
Manufacturer Part Number	0848529090000
Also known as	WS22308-E1-2RSR
EAN	4054364829582
Category	Spherical Roller Bearing

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	90
Width (B) MM	38
Inner (d) Inch	1.5748
Outer (D) Inch	3.5433
Width (B) Inch	1.4961
Weight (kg)	1.2 kg

Product Properties

Bore	C - Cylindrical Bore
Lubrication Enhancement	W33 - Lubrication Groove and 3 Holes
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution	Non Vibrating Screen Execution

Data from Schaeffler (medias)

Width (b) mm	38
Radial Static Load Rating C0r (N)	149000
Radial Dynamic Load Rating Cr (N)	156000
Limiting speed (n G)	1890
ECLASS number	23-05-09-11
ECLASS2 number	23-05-09-11
Medias description	Sealed spherical roller bearings WS223..-E1, lip seals on both sides, for continuous casting machines

Suffix description

E1	Increased Capacity Design
XL	X-Life
2RSR	Rubber Seals At Each Side Of The Bearing
