FAG RNU308-E-XL-TVP2

Specifications

Brand	FAG
Item Number	RNU308-E-XL-TVP2 FAG
Manufacturer Part Number	0192724560000
Also known as	RNU308-E-TVP2
EAN	4012801406567
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	52
Outer (D) MM	90
Width (B) MM	23
Inner (d) Inch	2.0472
Outer (D) Inch	3.5433
Width (B) Inch	0.9055
Weight (kg)	0.682 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Raceway diameter inner ring (F w) mm	52
Width (b) mm	23
Radial Static Load Rating C0r (N)	79000
Radial Dynamic Load Rating Cr (N)	96000
Basic static load rating, radial (C 0r)	"79000.0000"
Limiting speed (n G)	10900
Reference speed (n u03d1r)	7100
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RNU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU

Suffix description

E	Increased Load Capacity
XL	X-Life
TVP2	Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
