FAG RNU307-E-XL-TVP2

Specifications

Brand	FAG
Item Number	RNU307-E-XL-TVP2 FAG
Manufacturer Part Number	0382663000000
Also known as	RNU307-E-TVP2
EAN	4012801406505
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	46,2
Outer (D) MM	80
Width (B) MM	21
Inner (d) Inch	1.8189
Outer (D) Inch	3.1496
Width (B) Inch	0.8268
Weight (kg)	0.492 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Raceway diameter inner ring (F w) mm	46,2
Width (b) mm	21
Radial Static Load Rating C0r (N)	63000
Radial Dynamic Load Rating Cr (N)	76000
Basic static load rating, radial (C 0r)	"63000.0000"
Limiting speed (n G)	12600
Reference speed (n u03d1r)	7900
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RNU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU

Suffix description

E	Increased Load Capacity
XL	X-Life
TVP2	Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
