FAG RNU2213-E-XL-TVP2

Specifications

Brand	FAG
Item Number	RNU2213-E-XL-TVP2 FAG
Manufacturer Part Number	0192720730000
Also known as	RNU2213-E-TVP2
EAN	4026677540140
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	77,6
Outer (D) MM	120
Width (B) MM	31
Inner (d) Inch	3.0551
Outer (D) Inch	4.7244
Width (B) Inch	1.2205
Weight (kg)	1.45 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Raceway diameter inner ring (F w) mm	78,5
Width (b) mm	31
Radial Static Load Rating C0r (N)	182000
Radial Dynamic Load Rating Cr (N)	177000
Basic static load rating, radial (C 0r)	"182000.0000"
Limiting speed (n G)	8100
Reference speed (n u03d1r)	4100
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RNU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU

Suffix description

E	Increased Load Capacity
XL	X-Life
TVP2	Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
