FAG RNU2206-E-XL-M1A

Specifications

Brand	FAG
Item Number	RNU2206-E-XL-M1A FAG
Manufacturer Part Number	0192720060000
Also known as	RNU2206-E-M1A
EAN	4012801604437
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	37,5
Outer (D) MM	62
Width (B) MM	20
Inner (d) Inch	1.4764
Outer (D) Inch	2.4409
Width (B) Inch	0.7874
Weight (kg)	0.216 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	MA - Brass Cage, Centered on Outer Ring
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Raceway diameter inner ring (F w) mm	37,5
Width (b) mm	20
Radial Static Load Rating C0r (N)	50000
Radial Dynamic Load Rating Cr (N)	58000
Basic static load rating, radial (C 0r)	"50000.0000"
Limiting speed (n G)	21200
Reference speed (n u03d1r)	8000
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RNU..-E-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU

Suffix description

E	Increased Load Capacity
XL	X-Life
M1A	Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
