FAG RNU1017-XL-M1A

Specifications

Brand	FAG
Item Number	RNU1017-XL-M1A FAG
Manufacturer Part Number	0192715220000
Also known as	RNU1017-M1A
EAN	4026677561886
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	96,5
Outer (D) MM	130
Width (B) MM	22
Inner (d) Inch	3.7992
Outer (D) Inch	5.1181
Width (B) Inch	0.8661
Weight (kg)	0.76 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	MA - Brass Cage, Centered on Outer Ring
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Raceway diameter inner ring (F w) mm	96,5
Width (b) mm	22
Radial Static Load Rating C0r (N)	103000
Radial Dynamic Load Rating Cr (N)	93000
Basic static load rating, radial (C 0r)	"103000.0000"
Limiting speed (n G)	10400
Reference speed (n u03d1r)	4750
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RNU..-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU

Suffix description

XL	X-Life
M1A	Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
