FAG RNU1008-XL-M1
Price: 74.30 $
Specifications
| Brand | FAG |
| Item Number | RNU1008-XL-M1 FAG |
| Manufacturer Part Number | 0192714500000 |
| Also known as |
RNU1008-M1 |
| EAN | 4012801022002 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 47 |
| Outer (D) MM | 68 |
| Width (B) MM | 15 |
| Inner (d) Inch | 1.8504 |
| Outer (D) Inch | 2.6772 |
| Width (B) Inch | 0.5906 |
| Weight (kg) | 0.172 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Raceway diameter inner ring (F w) mm | 47 |
| Width (b) mm | 15 |
| Radial Static Load Rating C0r (N) | 30500 |
| Radial Dynamic Load Rating Cr (N) | 33500 |
| Basic static load rating, radial (C 0r) | "30500.0000" |
| Limiting speed (n G) | 20400 |
| Reference speed (n u03d1r) | 8900 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing RNU..-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU |
| XL | X-Life |
| M1 | Solid Brass Cage, Two Piece, Roller Guided |
