FAG QJ326-N2-MPA

FAG QJ326-N2-MPA
FAG QJ326-N2-MPA rulman resim 1
FAG QJ326-N2-MPA rulman resim 2
FAG QJ326-N2-MPA rulman resim 3
Price: 1,042.06 $
Specifications
Brand FAG
Item Number QJ326-N2-MPA FAG
Manufacturer Part Number 0192625070000
EAN 4012801268509
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 130
Outer (D) MM 280
Width (B) MM 58
Inner (d) Inch 5.1181
Outer (D) Inch 11.0236
Width (B) Inch 2.2835
Weight (kg) 19.2 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 58
Radial Static Load Rating C0r (N) 570000
Radial Dynamic Load Rating Cr (N) 425000
Basic static load rating, radial (C 0r) "570000.0000"
Limiting speed (n G) 4200
Reference speed (n u03d1r) 2220
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-N2-MPA, inner ring split
Suffix description
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
