FAG QJ313-XL-N2-MPA

FAG QJ313-XL-N2-MPA
FAG QJ313-XL-N2-MPA rulman resim 1
FAG QJ313-XL-N2-MPA rulman resim 2
FAG QJ313-XL-N2-MPA rulman resim 3
FAG QJ313-XL-N2-MPA rulman resim 4
Price: 233.86 $
Specifications
Brand FAG
Item Number QJ313-XL-N2-MPA FAG
Manufacturer Part Number 0385685000000
Also known as QJ313-N2-MPA
EAN 4026677475985
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 140
Width (B) MM 33
Inner (d) Inch 2.5591
Outer (D) Inch 5.5118
Width (B) Inch 1.2992
Weight (kg) 2.605 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 33
Radial Static Load Rating C0r (N) 145000
Radial Dynamic Load Rating Cr (N) 171000
Basic static load rating, radial (C 0r) "145000.0000"
Limiting speed (n G) 9600
Reference speed (n u03d1r) 4450
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
