FAG QJ307-XL-MPA-C3

FAG QJ307-XL-MPA-C3
FAG QJ307-XL-MPA-C3 rulman resim 1
FAG QJ307-XL-MPA-C3 rulman resim 2
FAG QJ307-XL-MPA-C3 rulman resim 3
Price: 65.63 $
Specifications
Brand FAG
Item Number QJ307-XL-MPA-C3 FAG
Manufacturer Part Number 0167424780030
Also known as QJ307-MPA-C3
EAN 4012801180849
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 80
Width (B) MM 21
Inner (d) Inch 1.378
Outer (D) Inch 3.1496
Width (B) Inch 0.8268
Weight (kg) 0.56 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 21
Radial Static Load Rating C0r (N) 46500
Radial Dynamic Load Rating Cr (N) 61000
Limiting speed (n G) 17900
Reference speed (n u03d1r) 7200
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
C3 Internal Clearance Larger Than Normal
