FAG QJ226-N2-MPA-F59-C4

FAG QJ226-N2-MPA-F59-C4
FAG QJ226-N2-MPA-F59-C4 rulman resim 1
FAG QJ226-N2-MPA-F59-C4 rulman resim 2
FAG QJ226-N2-MPA-F59-C4 rulman resim 3
FAG QJ226-N2-MPA-F59-C4 rulman resim 4
FAG QJ226-N2-MPA-F59-C4 rulman resim 5
Price: 895.23 $
Specifications
Brand FAG
Item Number QJ226-N2-MPA-F59-C4 FAG
Manufacturer Part Number 0384023600040
Also known as QJ226N2MA/C4B20
EAN 4012801267786
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 130
Outer (D) MM 230
Width (B) MM 40
Inner (d) Inch 5.1181
Outer (D) Inch 9.0551
Width (B) Inch 1.5748
Weight (kg) 7.29 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play C4 Internal Play (Higher than C3)
Precision A2 - Reduced Width Tolerance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 40
Radial Static Load Rating C0r (N) 370000
Radial Dynamic Load Rating Cr (N) 295000
Basic static load rating, radial (C 0r) "370000.0000"
Limiting speed (n G) 5100
Reference speed (n u03d1r) 2800
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-N2-MPA, inner ring split
Suffix description
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
F59 Replaced By
H68 Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications
C4 Bearing Internal Clearance Greater Than C3
