FAG QJ218-XL-N2-TVP
Price: 197.32 $
Specifications
| Brand | FAG |
| Item Number | QJ218-XL-N2-TVP FAG |
| Manufacturer Part Number | 0192610710000 |
| Also known as |
QJ218-N2-TVP |
| EAN | 4012801267632 |
| Category | Four Point Contact Ball Bearing |
| Inner (d) MM | 90 |
| Outer (D) MM | 160 |
| Width (B) MM | 50 |
| Inner (d) Inch | 3.5433 |
| Outer (D) Inch | 6.2992 |
| Width (B) Inch | 1.9685 |
| Weight (kg) | 2.35 kg |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| External Modification | N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 30 |
| Radial Static Load Rating C0r (N) | 198000 |
| Radial Dynamic Load Rating Cr (N) | 189000 |
| Basic static load rating, radial (C 0r) | "198000.0000" |
| Limiting speed (n G) | 5500 |
| Reference speed (n u03d1r) | 3750 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Four point contact bearings QJ2..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots |
| XL | X-Life |
| N2 | Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
