FAG QJ216-XL-N2-MPA-C4
Price: 285.21 $
Specifications
| Brand | FAG |
| Item Number | QJ216-XL-N2-MPA-C4 FAG |
| Manufacturer Part Number | 0167423380040 |
| Also known as |
QJ216-N2-MPA-C4 |
| EAN | 4012802026474 |
| Category | Four Point Contact Ball Bearing |
| Inner (d) MM | 80 |
| Outer (D) MM | 140 |
| Width (B) MM | 26 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 5.5118 |
| Width (B) Inch | 1.0236 |
| Weight (kg) | 1.75 kg |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 137000 |
| Radial Dynamic Load Rating Cr (N) | 136000 |
| Basic static load rating, radial (C 0r) | "137000.0000" |
| Limiting speed (n G) | 9400 |
| Reference speed (n u03d1r) | 4250 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split |
| XL | X-Life |
| N2 | Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA | Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| C4 | Bearing Internal Clearance Greater Than C3 |
