FAG NU2344-EX-M1A-C3

FAG NU2344-EX-M1A-C3
FAG NU2344-EX-M1A-C3 rulman resim 1
FAG NU2344-EX-M1A-C3 rulman resim 2
FAG NU2344-EX-M1A-C3 rulman resim 3
Price: 8,655.44 $
Specifications
Brand FAG
Item Number NU2344-EX-M1A-C3 FAG
Manufacturer Part Number 0389117280030
EAN 4026677038432
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 220
Outer (D) MM 460
Width (B) MM 145
Inner (d) Inch 8.6614
Outer (D) Inch 18.1102
Width (B) Inch 5.7087
Weight (kg) 120 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 145
Radial Static Load Rating C0r (N) 3350000
Radial Dynamic Load Rating Cr (N) 2350000
Basic static load rating, radial (C 0r) "3350000.0000"
Limiting speed (n G) 2110
Reference speed (n u03d1r) 830
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-EX-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
EX Increased Capacity Design, Design Modified In Accordance With Standard (Parts From These Bearings Must Not Be Interchanged With Parts From Bearings Of The Same Size Of The Previous Design E)
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
C3 Internal Clearance Larger Than Normal
