FAG NU2305-E-XL-M1A

FAG NU2305-E-XL-M1A
FAG NU2305-E-XL-M1A rulman resim 1
FAG NU2305-E-XL-M1A rulman resim 2
FAG NU2305-E-XL-M1A rulman resim 3
FAG NU2305-E-XL-M1A rulman resim 4
FAG NU2305-E-XL-M1A rulman resim 5
Price: 88.88 $
Specifications
Brand FAG
Item Number NU2305-E-XL-M1A FAG
Manufacturer Part Number 0192438120000
Also known as NU2305-E-M1A
EAN 4012801590907
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 24
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.9449
Weight (kg) 0.382 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 56000
Radial Dynamic Load Rating Cr (N) 67000
Basic static load rating, radial (C 0r) "56000.0000"
Limiting speed (n G) 21500
Reference speed (n u03d1r) 8200
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
