FAG NU2217-E-XL-MPAX-C4
Price: 409.76 $
Specifications
| Brand | FAG |
| Item Number | NU2217-E-XL-MPAX-C4 FAG |
| Manufacturer Part Number | 0814229380040 |
| Also known as |
NU2217-E-MPAX-C4 |
| EAN | 4054372852466 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 85 |
| Outer (D) MM | 150 |
| Width (B) MM | 36 |
| Inner (d) Inch | 3.3465 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.4173 |
| Weight (kg) | 2.75 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 36 |
| Basic static load rating, radial (C 0r) | 275000 |
| Limiting speed (n G) | 8300 |
| Reference speed (n u03d1r) | 3300 |
| E | Increased Load Capacity |
| XL | X-Life |
| MPAX | Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| C4 | Bearing Internal Clearance Greater Than C3 |
