FAG NU219-E-XL-M1A-C3
Price: 513.92 $
Specifications
| Brand | FAG |
| Item Number | NU219-E-XL-M1A-C3 FAG |
| Manufacturer Part Number | 0382632380030 |
| Also known as |
NU219-E-M1A-C3 |
| EAN | 4012801395113 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 95 |
| Outer (D) MM | 170 |
| Width (B) MM | 32 |
| Inner (d) Inch | 3.7402 |
| Outer (D) Inch | 6.6929 |
| Width (B) Inch | 1.2598 |
| Weight (kg) | 3.11 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 32 |
| Radial Static Load Rating C0r (N) | 265000 |
| Radial Dynamic Load Rating Cr (N) | 260000 |
| Basic static load rating, radial (C 0r) | "265000.0000" |
| Limiting speed (n G) | 7200 |
| Reference speed (n u03d1r) | 3650 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NU..-E-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU |
| E | Increased Load Capacity |
| XL | X-Life |
| M1A | Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
| C3 | Internal Clearance Larger Than Normal |
