FAG NU210-E-XL-M1-C3

FAG NU210-E-XL-M1-C3
FAG NU210-E-XL-M1-C3 rulman resim 1
FAG NU210-E-XL-M1-C3 rulman resim 2
FAG NU210-E-XL-M1-C3 rulman resim 3
FAG NU210-E-XL-M1-C3 rulman resim 4
FAG NU210-E-XL-M1-C3 rulman resim 5
Price: 98.43 $
Specifications
Brand FAG
Item Number NU210-E-XL-M1-C3 FAG
Manufacturer Part Number 0190079570030
Also known as NU210-E-M1-C3
EAN 4012801393577
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.532 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 69000
Radial Dynamic Load Rating Cr (N) 75000
Basic static load rating, radial (C 0r) "69000.0000"
Limiting speed (n G) 14500
Reference speed (n u03d1r) 6600
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C3 Internal Clearance Larger Than Normal
