FAG NU210-E-M1-F1-J20AA-R115-130NA

FAG NU210-E-M1-F1-J20AA-R115-130NA
FAG NU210-E-M1-F1-J20AA-R115-130NA rulman resim 1
FAG NU210-E-M1-F1-J20AA-R115-130NA rulman resim 2
Price: 427.37 $
Specifications
Brand FAG
Item Number NU210-E-M1-F1-J20AA.R115.130NA FAG
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.532 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Breakdown Voltage 1000v
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Suffix description
E Increased Load Capacity
M1 Solid Brass Cage, Two Piece, Roller Guided
F1 FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction"
J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments
R115.130NA Radial Clearance In u03bcm
