FAG NU2030-E-XL-M1-C3

Specifications

Brand	FAG
Item Number	NU2030-E-XL-M1-C3 FAG
Manufacturer Part Number	0380483370030
Also known as	NU2030-E-M1-C3
EAN	4012801232913
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	150
Outer (D) MM	225
Width (B) MM	45
Inner (d) Inch	5.9055
Outer (D) Inch	8.8583
Width (B) Inch	1.7717
Weight (kg)	6 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	M - Brass Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	45
Radial Static Load Rating C0r (N)	550000
Radial Dynamic Load Rating Cr (N)	410000
Basic static load rating, radial (C 0r)	"550000.0000"
Limiting speed (n G)	5600
Reference speed (n u03d1r)	980
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing NU20..-E-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU

Suffix description

E	Increased Load Capacity
XL	X-Life
M1	Solid Brass Cage, Two Piece, Roller Guided
C3	Internal Clearance Larger Than Normal
