FAG NU203-E-XL-M1A-C3

FAG NU203-E-XL-M1A-C3
FAG NU203-E-XL-M1A-C3 rulman resim 1
FAG NU203-E-XL-M1A-C3 rulman resim 2
Price: 56.57 $
Specifications
Brand FAG
Item Number NU203-E-XL-M1A-C3 FAG
Manufacturer Part Number 0387263270030
Also known as NU203-E-M1A-C3
EAN 4054364653590
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 17
Outer (D) MM 40
Width (B) MM 12
Inner (d) Inch 0.6693
Outer (D) Inch 1.5748
Width (B) Inch 0.4724
Weight (kg) 0.068 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 12
Radial Static Load Rating C0r (N) 14600
Radial Dynamic Load Rating Cr (N) 20800
Basic static load rating, radial (C 0r) "14600.0000"
Limiting speed (n G) 34000
Reference speed (n u03d1r) 15300
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
C3 Internal Clearance Larger Than Normal
